MULTI-TUBE SINGLE SHEATH STEEL TAPE CABLE (UP TO 144F)
Unleash the power of resilience with our Multi-Tube Single Sheath Steel Tape Cable (up to 144F). Designed for direct burial and inside duct installation, this cable offers unparalleled durability and protection.
With enhanced compressive strength and rodent resistance, your network remains secure even in the harshest environments. Lumiflex’s robust construction ensures uninterrupted connectivity from local loops to long-haul networks. Experience the freedom of a lightweight and flexible cable that defies limitations.
- Premium Quality
- Secure Payments
- Satisfaction Guarantee
- Worldwide Shipping
- Money Back Guarantee
Related products
Blue
Green
Slate
Red
Yellow
Pink
Orange
Brown
White
Black
Violet
Aqua\Natural
DRUM
Avail in 2Km & above
COIL
01 Kms & above
FRP 2
2 FRP
YARN
2 GFR
JACKET
HDPE
APPLICATIONS & FEATURES
- Suitable for direct burial & inside duct installation
- Improves compressive strength and rodent protection
- Local loop, metro, long-haul and broadband network
- Robust construction
- Light weight and flexible
- Available upto 144 fibers
CONSTRUCTION DETAILS
- Non metallic, anti-buckling FRP rod as Central Strength Member (CSM)
- Loose tube containing coloured fibers and filled with thixotropic jelly
- Cable core fully filled with flooding jelly
- S/Z core wrapped with polyester tape
- Electrolyte chrome coated corrugated steel tape armouring
- Fiber count 2F-144F (SM Fiber G.652D, G.655, G.657 and Multimode OM1, OM2, OM3 & OM4)
- Outer sheath with UV Stabilized HDPE compound
ENVIRONMENTAL CONDITIONS (IEC 60794-1-2-F1)
- Operating Temperature : -30˚C to + 70˚C
- Storage Temperature : -30˚C to + 70˚C
- Installation Temperature : -20˚C to + 70˚C
INTERNATIONAL STANDARDS
- IEC 60794; IEC 60793; ITU-T Rec. G.650; ITU-T Rec. G.652;
- ITU-T Rec. G.655; ITU-T Rec. G.656; ITU-T Rec G.657;
- EN 187000; Telecordia GR-20 issue 3rd May, 2008
OPTIONS AVAILABLE ON REQUEST
- Dry core construction (Gel free)/ Composite fibers/ Customized designs/Metallic CSM/Aramid or Glass Yarns/Rip Cord(s)/FR PVC/LSZH
DRUM LENGTH
- 2000 meters ± 10%
- As per customer’s requirement
TECHNICAL DATA
|
Fiber Count
|
Outer Diameter (Nominal)
|
Tensile Strength (N)
|
Bending Radius
|
|||
|---|---|---|---|---|---|---|
|
|
|
Temporary
|
Permanent
|
Temporary
|
Permanent
|
|
|
Upto 36F
|
9.8 mm (±0.2 mm)
|
1000
|
500
|
15D
|
20D
|
|
|
48F-72F
|
11.3 mm (±0.2 mm)
|
1600
|
800
|
15D
|
20D
|
|
|
96F
|
12.7 mm (±0.2 mm)
|
1600
|
800
|
15D
|
20D
|
|
|
144F
|
15.8 mm (±0.2 mm)
|
1600
|
800
|
15D
|
20D
|
|
FIBRE TRANSMISSION PERFORMANCE
|
Parameters
|
Multimode
|
Single Mode
|
|||
|---|---|---|---|---|---|
|
Fiber Core Diameter (µm)
|
62.5
|
50
|
50
|
50
|
9
|
|
Fiber Category
|
0M1
|
0M2
|
0M3
|
0M4
|
G652D and G657A1
|
|
Wavelengths (nm)
|
850/1300
|
850/1300
|
850/1300
|
850/1300
|
1310/1550/1625
|
|
Maximum Attenuation (dB/ km)
|
3.4/1.0
|
3.0/1.0
|
3.0/1.0
|
3.0/1.0
|
0.36/0.23/0.26
|
|
Bandwidth (MHz*km) 850/ 1300
|
200/500
|
500/500
|
1500/500
|
3500/500
|
N/A
|
